Haldex 3036 Combination Brake Chamber | GC3036

Description

The HDX GC3036 is a Haldex 3036 Combination Brake Chamber designed for use in air brake systems. This brake chamber is a crucial component in converting air pressure into mechanical force to actuate the brakes. The Haldex 3036 model is known for its reliability and performance in various heavy-duty applications.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Finish: Powder Coated
• Housing Material: Steel
• Chamber Type: 3036
• Maximum Pressure: 150 psi
• Stud Length: 1.50 in
• Stroke Length: 2.50 in
• Push Rod Length: 10 in
• Stud Thread Size: 5/8-11 UNC in
• Inlet Port Thread Size: 3/8-18 NPTF in
• Stud Distance: 120.7 mm
• Dimension At Rolled Spring Housing Flange: 9.10 in
• Dimension At Service Clamp band: 10.2 in
• Distance To Clevis Pin Centerline From Face Of Service Housing: 4.75 in
• Length From Mounting Bracket To Spring Housing End: 9.80 in
• Piggyback Length: 7.30 in
• Push Rod Length From Face Of Service Housing: 10 in
• Push Rod Thread Size: 5/8-18 UNF in
• Inlet Position Angle: 90 deg
• Air Port Thread Size: 3/8-18 NPTF in
• Quantity: 1
• Grade: 5
• Air Port Position: 90 deg
• Service Clamp band Position: 0 deg
