Bendix R-7 Spring Brake Valve | 103081N

Description

The Bendix R-7 Spring Brake Valve, model number BW 103081N, is a part of a vehicle's air brake system that focuses on enhancing safety and control. This valve, which has a silver design, ensures compliance with the FMVSS 121 standards that regulate air brake systems. It comes with an exhaust port featuring a dust shield orientation. It has a spring brake hold-off pressure of 95 psi to prevent braking. With its measurements of 146 mm in length, 5 mm in width and 129 mm in height, this valve incorporates threaded ports, including supply and delivery ports sized at 3/8-18 NPT as well as control and balance ports sized at 1/4-18 NPT. It operates efficiently within a temperature range spanning from -40° F to 200° F. The Bendix R-7 Spring Brake Valve plays a role in maintaining the reliability and safety of a vehicle's air brake system by controlling the engagement and disengagement of the spring brakes.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Construction Color: Silver
• Exhaust Port Type: Dust Shield
• Spring Brake Hold-Off Pressure: 95 psi
• Anti-Compounding: Yes
• Regulatory Compliance: FMVSS 121
• Exhaust Orientation: Exhaust Facing Up
• Length: 146 mm
• Width: 5 mm
• Height: 129 mm
• Thread Size: 3/8-18 in
• Mounting Dimension: 0.41 in
• Supply Port Thread Size: 3/8-18 NPT in
• Control Port Thread Size: 1/4-18 NPT in
• Balance Port Thread Size: 1/4-18 NPT in
• Delivery Port 1 Thread Size: 3/8-18 NPT in
• Delivery Port 2 Thread Size: 3/8-18 NPT in
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 200 Deg. F
