Meritor Right-Hand Thread Tie Rod End | R230069

Description

The TDA R230069 is a type of tie rod end that is designed for the right-hand side of a vehicle's steering mechanism. It plays a role in ensuring safe steering movements. With its construction, it features two taper diameters, one measuring 1.102 inches and a smaller one measuring 0.967 inches. The rod thread has a diameter of 1.125 inches with 12 threads per inch, while the stud thread measures 0.875 inches with 14 threads per inch. These specifications make it highly durable. Additionally, it has a taper length of 1.08 inches and includes a Zerk for effective lubrication on the curbside of the vehicle. The tie rod end acts as a connection between the steering system and the wheels, ensuring control over steering movements and enhancing overall driving accuracy and safety.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Type: 1
• Large Taper Diameter: 1.102 in.
• Rod Thread Diameter: 1.125 in.
• Rod Threads per in: 12
• Rod Thread Direction: RH
• Notes: Zerk on bottom
• Small Taper Diameter: 0.967 in.
• Stud Center to Rod End: 5.44 in.
• Stud Thread Diameter: 0.875 in.
• Stud Threads per in: 14
• Style: Curbside
• Taper Length: 1.08 in.
