Meritor Left-Hand Thread Tie Rod End | R230068
Have a Question for Our Team?
Description
The TDA R230068 is a component that forms part of a vehicle's steering system and is known as a left-hand thread tie rod end. It is designed to be durable with a sturdy construction and specific taper diameters of 1.102 inches (and 0.967 inches (small). The rod thread diameter measures 1.125 inches with 12 threads per inch, while the stud thread diameter is 0.875 inches with 14 threads per inch. This tie rod end is positioned on the roadside of the vehicle and has a taper length of 1.08 inches, making it easy to lubricate using its Zerk fitting. Its main function is to connect the steering system to the wheels, allowing for controlled steering movements that enhance driving stability and safety.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Type: 1
- Large Taper Diameter: 1.102 in.
- Rod Thread Diameter: 1.125 in.
- Rod Threads per in: 12
- Rod Thread Direction: LH
- Notes: Zerk on bottom
- Small Taper Diameter: 0.967 in.
- Stud Center to Rod End: 5.44 in.
- Stud Thread Diameter: 0.875 in.
- Stud Threads per in: 14
- Style: Roadside
- Taper Length: 1.08 in.
| AUTOCAR | 37019, 370240005, L24SV5042A12 | |
|---|---|---|
| BLUEBIRD | 4279535 | |
| CHRYSLER | 3744496, L24SV5042A12 | |
| DANA | 140TR110, SP692244 | |
| DAYTON PARTS BATCO | 310223, 310223E | |
| EATON | 1006148, 1006149, L24SV5042A12 | |
| FORD | D0HZ3A130A, D0HZ3A130D, E3HZ3A130A, E4HZ3A130A, E4HZ3A130B | |
| FEDERAL MOGUL | ES3218R, ES423R, L24SV4000H11, L24SV5042A14 | |
| FLAGG | ES423R | |
| FREIGHTLINER | A3144D524, L24SV5042A12, L24SV5042B12 | |
| GENERAL MOTORS CORP. | 00698572, 15515805, 698572, L24SV5042A12 | |
| INDUSTRY | ES423R | |
| INTERCITY DIST.(CAN) | ES423R, ES423RI | |
| KENWORTH | A3144D524, L24SV5042A12 | |
| MACK | A3144D524 | |
| MARMON | A3144D524, L24SV5042A12 | |
| MOOG | ES423R | |
| NAVISTAR | 1668408C91, 1681456C91, 438369C91, 507838C91, FTR423R, FTR8408 | |
| O AND S MFG. | E11003, ES423R | |
| PAI | ARE9988 | |
| PERFECT CIRCLE | 2692244 | |
| PETERBILT | A3144D524, L24SV5042A12 | |
| PROVINCIAL WHSE -CAN | MES423R | |
| SPICER | SP692244 | |
| TRW | ES3218R, ES423R, L20SV8101D12, L20SV8101D15, L20SV8103D12, L20SV8103K12, L20SV8103D21, L24SV4000H11, L24SV5042A12, L24SV5042A14, L24SV5043A12 | |
| TW HEAVY VEHICLE PTS | ES423R | |
| TRAILMOBILE | 384615 | |
| VOLVO | 370240005, 370245010, A3144D524, L24SV5042A12, V1091563 | |
| WHITE TRUCK | 027092085, 370240005, 370245010, V1112812 | |
| WORLD AMERICAN PARTS | MW423R | |
| ZF | 41035BLW0 | |
| OTHER | OTR26151, QTE967R, R0029142, R230069RI, R230128, RAR230069, RFR230069, ROR230069, S7357, SES423R, TDAA3144D524, TDAA3144P1134, TDAR230069, TDAR230128, TE2030, TR423R, TRE11003, WA423R |
| Manufacturer | Meritor |
|---|---|
| Shipping Length (in) | 8.00 |
| Shipping Width (in) | 8.00 |
| Shipping Height (in) | 6.00 |
| Returnable | Yes |
| Weight (lb) | 3.34 |
| Core Exchange | No |
