Truck-Lite 36 Series LED Rectangular Marker Light - Red | 36203R

Description

The Truck-Lite TL 36203R is a marker clearance light belonging to the 36 Series. Its purpose is to ensure visibility and reliable illumination on vehicles. You can trust this light as it complies with FMVSS 108, CMVSS 108 DOT and SAE regulations, meeting industry standards. With its lens, you'll have clear and noticeable signaling. The lens is made of material that can withstand impacts. It has a height of 0.55 inches (13.97 mm) and a width of 1.89 inches (48.01 mm). The light's housing is also constructed with polycarbonate for protection and durability. Its black mount/trim color gives it an attractive appearance when installed using adhesive on surfaces. By utilizing LED technology, the TL 36203R offers energy efficiency and an extended lifespan. Operating at a voltage of 12V, it contains three diodes/bulbs that emit reliable illumination while drawing a minor current of 0.01 Amps. This marker clearance light is designed to be compact and versatile with a depth of 6 inches (152.4 mm), a height of 0.76 inches (19.3 mm), a total length of 0.06 inches (1.52 mm) and a total width of 1.89 inches (48.01 mm). The TL 36203R is built to be sealed against moisture, ensuring performance in many applications. Its lamp connection is hardwired with three wires for installation.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Brand: Truck-Lite
• Category: Marker Clearance Light
• Series: 36 Series
• Compliance Family: FMVSS 108|CMVSS 108|DOT|SAE
• Current Minor: 0.01 Amps
• Diamond Shell: No
• Housing Material: Polycarbonate
• KIT: No
• Lens Shape: Rectangular
• Lighting Technology: LED
• Lamp Connection: Hardwired
• Lens Color: Red
• Lens Height: 0.55 in (13.97 mm)
• Lens Material: Polycarbonate
• Lens Width: 1.89 in (48.01 mm)
• Mount/Trim Color: Black
• Mount/Trim Material: PVC
• Mount Type: Adhesive Mount
• Number of Diodes/Bulbs: 3
• Number of Wires: 3
• Plug Side One: Hardwired
• Plug Side Two: 0.180 Bullet
• Sealed/Bulb Replaceable: Sealed
• Standards Met: P2
• Total Depth: 6 in (152.4 mm)
• Total Height: 0.76 in (19.3 mm)
• Total Length: 0.06 in (1.52 mm)
• Total Width: 1.89 in (48.01 mm)
• Voltage: 12V
