In Stock!
Spicer Half Round End Yoke | 6.5 4 4631 1
SKU
SP 6.5 4 4631 1
MPN
6.5 4 4631 1
$166.58
Have a Question for Our Team?
Our Customer Service team is ready to help.
Call 1.877.DL.ORDER or Email Us
Monday - Friday 8 AM - 4:30 PM ET
Description
The SP 6.5 4 4631 1 is an end yoke designed for the rear driving axle of a vehicle. It is a crucial component in the driveline system, connecting the driveshaft to the rear axle and facilitating power transfer from the transmission to the wheels. The specific part number indicates the dimensions and specifications of the end yoke, ensuring it is compatible with the intended application.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Spline Quantity: 54
- Series: 1810
- Slinger/Plug included: No
- Yoke Style: HR
- Material: Steel
- Type: Splined Hole
- Involute Spline: Yes
- Major Diameter: 2.79 in
- Yoke Bearing Diameter: 1.94 in
- Hole Length: 2.75 in
- Universal Joint Retaining Width: 7.64 in
- Outer Yoke Length: 7.64 in
- Bearing Center to Hub End Length: 5.63 in
- Joint Angle 2: 30 deg
| Manufacturer | Spicer |
|---|---|
| Shipping Length (in) | 14.00 |
| Shipping Width (in) | 10.00 |
| Shipping Height (in) | 10.00 |
| Returnable | Yes |
| Weight (lb) | 15.85 |
| Core Exchange | No |
