Road Choice Spring Brake 30/30 Spring Brake without Clevis | SB3030STD

Description

The SB3030STD is a Road Choice Spring Brake featuring a 30/30 spring brake design and is supplied without a clevis. This component is crucial for the braking system, offering reliable spring brake functionality and ensuring effective vehicle stopping power. Built for durability and performance, the SB3030STD supports safe vehicle operation by maintaining optimal braking efficiency.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Product Type: Spring Brakes
• Chamber Type: 30 / 30
• Stroke Length (in): 2.50
• Stroke Length (mm): 63.50
• Push Rod Length (in): 7.80
• Push Rod Length (mm): 198.12
• Height (in): 9.50
• Height (mm): 241.30
• Mounting Bolt Length (in): 1.50
• Mounting Bolt Length (mm): 38.10
• Bolt Hole Size: 0.63
• Bolt Circle (in): 4.75
• Bolt Circle (mm): 120.65
• Clevis: Threaded Yoke 5/8" - 18 UNF
• Ports: Round
• Housing Diameter (in): 5.7
• Clamp Diameter (in): 8.3
• Diaphragm Diameter (in): 8
• Rod Size (in): 5/8-18
