Road Choice Spring Brake 30/30 Long Stroke without Clevis | SB3030LS

Description

The SB3030LS is a Road Choice Spring Brake, featuring a 30/30 long stroke design and is supplied without a clevis. This component is essential for the braking system, providing reliable spring brake functionality and ensuring effective vehicle stopping power. Engineered for durability and consistent performance, the SB3030LS supports the safe operation of heavy-duty vehicles by maintaining optimal braking efficiency.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Chamber Type: 30 / 30
• Stroke Length (in): 3.00
• Stroke Length (mm): 76.20
• Push Rod Length (in): 8.00
• Push Rod Length (mm): 203.20
• Height (in): 10.31
• Height (mm): 261.87
• Mounting Bolt Length (in): 1.50
• Mounting Bolt Length (mm): 38.10
• Bolt Hole Size: 0.63
• Bolt Circle (in): 4.75
• Bolt Circle (mm): 120.65
• Clevis: Threaded Yoke 5/8" - 18 UNF
• Ports: Square
• Housing Diameter (in): 5.7
• Clamp Diameter (in): 8.3
• Diaphragm Diameter (in): 8
• Rod Size (in): 5/8-18
