Philips Halogen Sealed Beam | H6054C1
Have a Question for Our Team?
Description
The PLC H6054C1 is a versatile halogen-sealed beam, adeptly handling both high and low-beam duties. Operating at 12.8 V, its high-beam filament draws 5.08 A, while the low-beam filament draws 2.73 A, culminating in a combined draw of 5.08 A when both filaments are engaged. Presenting itself as a standard sealed beam type, this bulb adopts a crystal-clear hue and exhibits a bulb base equipped with 3 contact lugs. It is legal for street use by receiving validation through Department of Transportation approval. The bulb manifests a high-beam power rating of 65 W and a low-beam power rating of 35 W. Its physical dimensions include a length of 5.63 inches and a diameter of 5.63 inches.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Bulb Technology: Halogen
- Filament Quantity: 2
- Filament Type: C-6
- Street Legal: Yes
- Halogen: Yes
- Department Of Transportation Approved: Yes
- Voltage: 12.8 V
- Ampere Rating: 5.08/2.73 A
- Power: 65/35 W
- Bulb Type: Standard Sealed Beam
- Bulb Color: Clear
- Bulb Base Type: 3 Contact Lugs
- Bulb Finish: Clear
- Beam Type: High-Beam Low-Beam
- Bulb Material: Glass
- Power Rating: 65/35 W
- Length: 5.63 in
- Diameter: 5.63 in
| FLEETRITE | FLTH6054 | |
|---|---|---|
| FREIGHTLINER CORPORATION | PLC H6054C1 | |
| GENERAL ELECTRIC CO. | H6054 | |
| NAVISTAR INTERNATIONAL TRANSPORTATION CORP. | GEDH6054, TUNH 6054 | |
| PARTS FOR TRUCKS INC | GEC-H6054 | |
| TRP PARTS | H6054CEC | |
| TRUCKPRO LLC | GEH6054C1 |
| Manufacturer | Philips |
|---|---|
| Shipping Length (in) | 8.00 |
| Shipping Width (in) | 8.00 |
| Shipping Height (in) | 6.00 |
| Returnable | No |
| Weight (lb) | 2.04 |
| Core Exchange | No |
