Meritor Wabco Type 24 Service Brake Chamber Right Hand | 423 106 008 0
Have a Question for Our Team?
Description
The WAB 423 106 008 0 model is a brake chamber made by Meritor Wabco. It is specifically designed to be used on the right side of vehicles. Brake chambers like this one play a vital role in the air brake system of vehicles. They convert air pressure into mechanical force to activate the service brakes of the vehicle. Proper maintenance and timely replacement of these brake chambers are essential to ensure the safe and efficient functioning of a vehicle's braking system. Meritor Wabco is a well-established manufacturer known for producing high-quality air brake and control systems that are widely used in heavy-duty and commercial vehicles across various applications.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Working Temperature Range: -40 to +185 Deg. F
- Weight: 3.70 kg
- Yoke Included: Yes
- Version: Without Boot
- Type: 24
- Operation Type: Cam
- Width: 107 mm
- Outer Diameter: 186 mm
- Overall Length: 4.69 in
- Bolt Length: 1.54 in
- Stroke Length: 2.99 in
- Bolt Thread Size: 5/8-11 UNC in
- Push Rod Length: 3.55 in
- Port Thread Size: 3/8-18 NPTF in
- Bolt Hole Center To Center Length: 4.75 in
- Push Rod Thread Size: 3/8 in
- Clevis Pin Diameter: 0.51 in
- Maximum Operating Pressure: 116 psi
- Working Pressure: 116 psi
- Maximum Pressure: 145 psi
- Spring Force: 39.34 lb. Ft
- Output Force: 1686.07 lb. Ft
| MERITOR | 4231060080 | |
|---|---|---|
| FREIGHTLINER | WAB4231060080 |
| Manufacturer | Meritor Wabco |
|---|---|
| Shipping Length (in) | 14.00 |
| Shipping Width (in) | 10.00 |
| Shipping Height (in) | 10.00 |
| Returnable | Yes |
| Weight (lb) | 7.28 |
| Core Exchange | No |
