Meritor Wabco Service Brake Chamber Assembly, D3030, 300, WC225, 020, 135 | 925 392 073 0

Description

The WAB 925 392 073 0 Meritor Wabco Service Brake Chamber Assembly, with specifications D3030, 300, WC225, 020, 135, is a vital component designed to ensure reliable braking performance in your vehicle. Crafted by Meritor Wabco, a leading manufacturer of brake system components, this assembly includes a high-quality brake chamber tailored for optimal functionality. With its durable construction and precise specifications, it provides consistent brake force and modulation, contributing to safe and controlled braking. Trust in this brake chamber assembly to maintain the integrity and effectiveness of your vehicle's braking system, ensuring dependable operation on the road.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Maximum Operating Pressure: 145 psi
• Release Pressure: 66.72 psi
• Working Temperature Range: -40 to +185 Deg.F
• Type: 30/30
• Operation Type: Cam
• Version: Without Boot
• Overall Length: 14.29 in
• Bolt Length: 1.50 in
• Stroke Length: 2.99 in
• Volume: 6 L
• Bolt Thread Size: 5/8-11 UNC in
• Push Rod Length: 3.55 in
• Bolt Hole Center To Center Length: 4.75 in
• Port 1 Thread Size: 3/8-18 NPTF in
• Port 2 Thread Size: 3/8-18 NPTF in
• Clevis Pin Diameter: 0.51 in
• Port Angle: 20 deg
• Port 12 Thread Size: 3/8-18 NPTF in
• Port 11 Thread Size: 3/8-18 NPTF in
