Meritor Wabco Normally Closed High Flow Solenoid, 12 Volt | 472 170 012 0

Description

The WAB 472 170 012 0 is a Normally Closed High Flow Solenoid designed to operate at 12 volts. It has an ampere rating of 1410 mA and an IP rating of IP 6K8/IP 6K9K, indicating its resistance to dust and high-pressure water. This solenoid is suitable for controlling compressed air and can handle a maximum operating pressure of 188.50 psi. With a working temperature range from -40 to +185 degrees Fahrenheit, it can operate reliably in a variety of environments. The HDSCS Code C connection type ensures secure and efficient fluid flow control when energized.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• IP Rating: IP 6K8/IP 6K9K
• Voltage: 12 V
• Ampere Rating: 1410 mA
• Volume: 0.39 L
• Exhaust Port Diameter: 4 mm
• Nominal Diameter: 0.16 in
• Inlet Port Thread Size: V16X1.5 mm
• Supply Port Thread Size: V16X1.5 mm
• Exhaust Port Thread Size: V16 x 1.5 mm
• Port 1 Thread Size: V16 x 1.5 mm
• Port 2 Thread Size: V16 x 1.5 mm
• Push Rod Thread Size: M16 x 1.5 mm
• Type: Normally Closed
• Coolant Type: Compressed Air
• Connection Type: HDSCS Code C
• Maximum Operating Pressure: 188.50 psi
• Working Temperature Range: -40 to +185 Deg. F
