Meritor Wabco Normally Closed High Flow Solenoid, 12 Volt | 472 170 002 0

Description

The WAB 472 170 002 0 is a Normally Closed High Flow Solenoid designed to operate at 12 volts. It has an ampere rating of 1410 mA and an IP rating of IP 6K6K/IP 6K9K, indicating its resistance to dust and water. The solenoid can handle a maximum operating pressure of 147.94 psi and is suitable for a wide temperature range from -40 to +185 degrees Fahrenheit. With its HDSCS Code A connection type, this solenoid is reliable and efficient for controlling fluid flow in various applications, ensuring precise and responsive operation when energized.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Voltage: 12 V
• Ampere Rating: 1410 mA
• IP Rating: IP 6K6K/IP 6K9K
• Maximum Operating Pressure: 147.94 psi
• Working Temperature Range: -40 to +185 Deg. F
• Volume: 0.34 L
• Exhaust Port Diameter: 4 mm
• Nominal Diameter: 0.16 in
• Inlet Port Thread Size: V16X1.5 mm
• Supply Port Thread Size: V16X1.5 mm
• Port 1 Thread Size: M16 x 1.5 mm
• Port 2 Thread Size: V16 x 1.5 mm
• Type: Normally Closed
• Connection Type: HDSCS Code A
