Meritor Wabco Foot Valve Assembly | 461 332 008 0
SKU
WAB 461 332 008 0
MPN
461 332 008 0
$121.12
Have a Question for Our Team?
Our Customer Service team is ready to help.
Call 1.877.DL.ORDER or Email Us
Monday - Friday 8 AM - 4:30 PM ET
Description
The WAB 461 332 008 0 is a Wabco Foot Valve Assembly used in air brake systems. It features a flap exhaust type and can handle a maximum operating pressure of 134.89 psi. The valve has a nominal diameter of 0.39 inches and various port thread sizes including 3/8-18 NPTF for inlet delivery port 21, port 12 and port 11. The assembly is designed to operate in a wide temperature range from -40 degrees Fahrenheit to 230 degrees Fahrenheit. It is equipped with two mounting holes for easy installation in the air brake system, ensuring precise and reliable control of the braking function.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Exhaust Type: Flap
- Maximum Operating Pressure: 134.89 psi
- Maximum Pressure: 3.05 psi
- Nominal Diameter: 0.39 in
- Inlet Port Thread Size: 3/8-18 NPTF in
- Delivery Port Thread Size: 3/8-18 NPTF in
- Mounting Hole Thread Size: 5/16-18 UNC in
- Port 21 Thread Size: 3/8-18 NPTF in
- Port 12 Thread Size: 3/8-18 NPTF in
- Port 11 Thread Size: 3/8-18 NPTF in
- Minimum Operating Temperature: -40 Deg. F
- Maximum Operating Temperature: 230 Deg. F
- Mounting Hole Quantity: 2
| AMBIGUOUS | S4613320080 |
|---|
| Manufacturer | Meritor Wabco |
|---|---|
| Shipping Length (in) | 8.00 |
| Shipping Width (in) | 8.00 |
| Shipping Height (in) | 6.00 |
| Returnable | Yes |
| Weight (lb) | 2.33 |
| Core Exchange | No |
