Meritor Wabco Air Disc Brake Chamber, D1824, 090, 270 | 925 347 027 0

Description

The WAB 925 347 027 0 represents a Wabco Air Disc Brake Chamber known as the D1824 090 270 model. It is specifically designed to be integrated into automotive air disc brake systems. The performance specifications include a maximum working pressure of 145 psi and a working pressure of 116 psi. It has the capability to function effectively within a temperature range spanning from -40 to +80 degrees Celsius. When it comes to dimensions, the brake chamber measures approximately overall length of about 283.50 mm, overall height of around 194 mm, an inlet port diameter of approximately 11 mm and a minimum stroke length of about 64 mm. This particular brake chamber plays a vital role in the air brake system by facilitating the activation and release of disc brakes in vehicles.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Maximum Working Pressure: 145 psi
• Working Pressure: 116 psi
• Working Temperature Range: -40 to +80 Deg.C
• Overall Length: 283.50 mm
• Overall Height: 194 mm
• Inlet Port Diameter: 11 mm
• Minimum Stroke Length: 64 mm
