Meritor Wabco ABS Combo Valve 4 PSI, 6x4 | 472 500 122 0

Description

The WAB 472 500 122 0 valve is a combination valve with a pressure rating of 4 psi. It is built to function under a maximum operating pressure of 159.50 psi and has a response pressure of 4.06 psi. The valve is suitable for both system configurations, the 4S/4M and the 6S/4M systems. It can perform reliably across a temperature range from -40 to +80 degrees Celsius.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• IP Rating: IP66, IP69K
• Voltage: 12 V
• Inlet Port Thread Size: 1/2-14 NPTF in
• Outlet Port Thread Size: 3/8-18 NPTF in
• Delivery Port Thread Size: 1/2-14 NPTF in
• Control Port Thread Size: 1/4-18 NPTF in
• Port 1 Thread Size: 1/2-14 NPTF in
• Port 2 Thread Size: 3/8-18 NPTF in
• Port 4 Thread Size: 1/4-18 NPTF in
• System Type: 4S/4M 6S/4M
• Connection Type: Bayonet Coupling
• Maximum Operating Pressure: 159.50 psi
• Response Pressure: 4.06 psi
• Working Temperature Range: -40 to +80 Deg.C
