Meritor Wabco 5.5 PSI, 6x4, ABS Combo Valve | 472 500 123 0

Description

The WAB 472 500 123 0 is a 6x4 ABS Combo Valve with a pressure rating of 5.5 PSI. It features an IP rating of IP66 and IP69K, providing excellent protection against dust and water ingress. The valve operates at a maximum pressure of 159.50 psi and has a response pressure of 5.51 psi. It is designed for both 4S/4M and 6S/4M system types with various port thread sizes, making it versatile and suitable for different connections. The valve can withstand a working temperature range from -40 to +80 degrees Celsius, ensuring reliable performance in various environments.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• IP Rating: IP66, IP69K
• Voltage: 12 V
• Volume: 6.16 L
• Inlet Port Thread Size: 1/2-14 NPTF
• Outlet Port Thread Size: 3/8-18 NPTF
• Delivery Port Thread Size: 1/2-14 NPTF
• Control Port Thread Size: 1/4-18 NPTF
• Port 1 Thread Size: 1/2-14 NPTF
• Port 2 Thread Size: 3/8-18 NPTF
• Port 4 Thread Size: 1/4-18 NPTF
• System Type: 4S/4M 6S/4M
• Connection Type: Bayonet Coupling
• Maximum Operating Pressure: 159.50 psi
• Response Pressure: 5.51 psi
• Working Temperature Range: -40 to +80 Deg. C
