Meritor RPL25 End Yoke | 25WYS50 1C

Description

The TDA 25WYS50 1C Meritor RPL25 End Yoke plays a vital role in the driveline system of heavy-duty vehicles. It serves as a crucial connection point between the driveline and the rear axle, enabling power transfer from the transmission to the wheels. Its primary function is to ensure smooth and efficient operation of the driveline, allowing the vehicle to move forward. It is important to regularly maintain and replace the end yoke when necessary to ensure optimal performance and reliability of the vehicle's driveline.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Number of Spline: 30
• Series: RPL25
• Spline Diameter: 3.175 in.
• Hub Diameter: 3.74 in.
• Spline Length: 2.95 in.
• Use U-Joint Kit: CP25RPLS
• Joint Angle: 24 degrees
• Counter Bore Depth: 0.73 in.
• Face To End: 5.83 in.
• Comments: Painted
• Bearing Cap Diameter: 2.06 in.
• Use Kit: KIT RPL 25 20
• Yoke Dimension Across Nibbs: 8.38 in.
