Meritor Right-HandThread Tie Rod End | R230104

Description

The TDA R230104 represents a tie rod end that is threaded on the right-hand side. It is also commonly known as ES3030R in the industry. This particular tie rod end is specifically designed for the curbside of a vehicle and falls under Type 3 category. It features a larger taper diameter of 1.25 inches and a smaller taper diameter of 1.08 inches. The rod thread diameter measures 1.875 inches with 12 threads per inch, while the stud thread diameter measures 0.875 inches with 14 threads per inch. The distance between the stud center and rod end is approximately 12.688 inches. To ensure easy maintenance and durability, this tie rod end comes equipped with lubrication fittings. Its primary function is to facilitate precise and responsive steering control by transmitting motion from the steering gear to the wheels in the vehicle's steering system.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Type: 3
• Industry Number: ES3030R
• Large Taper Diameter: 1.25 in.
• Rod Thread Diameter: 1.875 in.
• Rod Threads per in: 12
• Rod Thread Direction: RH
• Notes: Lubrication fittings installed
• Small Taper Diameter: 1.08 in.
• Stud Center to Rod End: 12.688 in.
• Stud Thread Diameter: 0.875 in.
• Stud Threads per in: 14
• Style: Curbside
• Taper Length: 1.36 in.
