Meritor Right-HandThread Tie Rod End | R230073

Description

The TDA R230073, also known as ES2091R in the industry, is a right-hand thread tie rod end used in a vehicle's steering system. It has a larger taper diameter of 1.25 inches and a smaller taper diameter of 1.08 inches. The rod thread diameter measures 1.25 inches with 12 threads per inch, while the stud thread diameter measures 0.875 inches with 14 threads per inch. This tie rod end is specifically designed for the curbside of the vehicle and has a taper length of 1.36 inches. To ensure proper lubrication, it features a Zerk fitting at the bottom. The tie rod end plays an important role in transmitting steering motion from the steering gear to the wheels, resulting in smooth and precise steering control.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Type: 1
• Industry Number: ES2091R
• Large Taper Diameter: 1.25 in.
• Rod Thread Diameter: 1.25 in.
• Rod Threads per in: 12
• Rod Thread Direction: RH
• Notes: Zerk on bottom
• Small Taper Diameter: 1.08 in.
• Stud Center to Rod End: 7.37 in.
• Stud Thread Diameter: 0.875 in.
• Stud Threads per in: 14
• Style: Curbside
• Taper Length: 1.36 in.
