Meritor Left-Hand Thread Tie Rod End | R230105

Description

The TDA R230105 represents a left-hand thread tie rod end that is also known in the industry as ES3031L. This specific tie rod end is intended to be used on the side of the vehicle that faces the roadside. It falls under Type 3 classification for tie rod ends. It has a taper diameter of 1.25 inches and a smaller taper diameter of 1.08 inches. The diameter of the rod's threading measures 1.875 inches with a thread count of 12 per inch, while the stud's threading has a diameter of 0.875 inches with a thread count of 14 per inch. The distance from the center of the stud to the end of the rod measures 12.688 inches. Additionally, this tie rod end comes equipped with lubrication fittings that make maintenance easier and contribute to its longevity.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Type: 3
• Industry Number: ES3031L
• Large Taper Diameter: 1.25 in.
• Rod Thread Diameter: 1.875 in.
• Rod Threads per in: 12
• Rod Thread Direction: LH
• Notes: Lubrication fittings installed
• Small Taper Diameter: 1.08 in.
• Stud Center to Rod End: 12.688 in.
• Stud Thread Diameter: 0.875 in.
• Stud Threads per in: 14
• Style: Roadside
• Taper Length: 1.36 in.
