Meritor 90-Degree ABS Wheel Speed Sensor | R955341

Description

The TDA R955341 is an ABS Wheel Speed Sensor that operates at a 90-degree angle. This sensor plays a role in the Anti-Lock Braking System (ABS) of vehicles. Its main function is to monitor the speed of a wheel and send this information to the ABS control module in the vehicle. By doing this, it allows the ABS system to identify wheel lockup during braking and make necessary adjustments to prevent skidding by regulating brake pressure. This sensor greatly contributes to safety as it prevents wheel lockup and ensures braking performance in challenging driving conditions, such as slippery or hazardous roads.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Brand: WABCO
• Length: 5.58 ft.
• Connector Type: DIN 2 PIN FEMALE
• Sensor Type: 90-Degree
• Length (Metric): 1.7 m
• Application Information: Installed at wheel ends to measure the motion of a sensed wheel in ABS applications.
• Cable Diameter: 4.4 mm
• Notes: Sensor kits include sensor with cable leads, sensor clip (S899 759 815 4), grease packet (S884 490 307 4) and instruction sheets.
• Cable Type: TRD
• Sensor Part: S441 032 813 0
• Wire Type: CS
