Haldex Spring Brake Assembly | GC2430XL

Description

The HDX GC2430XL Haldex Spring Brake Assembly provides emergency parking and auxiliary braking capabilities. This spring brake assembly functions by utilizing compressed air to release the spring brakes, allowing the vehicle to move. In cases where there is a loss or reduction in air pressure, the spring brakes automatically engage to secure the vehicle in a parked position, preventing any unintended movement. Specifically designed for heavy-duty applications, the HDX GC2430XL spring brake assembly ensures reliable and efficient operation of the air brake system.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Finish: Powder Coated
• Housing Material: Steel
• Chamber Type: 2430
• Stroke Length: 3 in
• Push Rod Length: 10 in
• Stud Distance: 120.7 mm
• Dimension At Rolled Spring Housing Flange: 8.30 in
• Dimension At Service Clamp band: 9.4 in
• Distance To Clevis Pin Centerline From Face Of Service Housing: 4.75 in
• Length From Mounting Bracket To Spring Housing End: 9.90 in
• Piggyback Length: 7.40 in
• Push Rod Length From Face Of Service Housing: 10 in
• Inlet Position Angle: 90 deg
• Air Port Position: 90 deg
• Service Clamp band Position: 0 deg
