Haldex Long Stroke Long Pushrod Brake Chamber 3030 | GC3030LR

Description

The HDX GC3030LR brake chamber is specially designed for heavy-duty commercial vehicles. It plays a crucial role in the air brake system by converting compressed air pressure into mechanical force, activating the vehicle's brakes. This long stroke design is ideal for heavy-duty applications that require enhanced braking performance, as it provides increased brake force and significant brake application. The extended pushrod allows for effective braking even in demanding conditions. With its strong construction and dependable performance, the HDX GC3030LR is essential for ensuring safety and efficient braking in heavy-duty vehicles.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Grade: 5
• Air Port Position: 90 deg
• Service Clamp band Position: 0 deg
• Finish: Powder Coated
• Housing Material: Steel
• Stud Length: 1.50 in
• Stroke Length: 3 in
• Stud Thread Size: 5/8-11 UNC in
• Inlet Port Thread Size: 3/8-18 NPTF in
• Stud Distance: 120.7 mm
• Dimension At Rolled Spring Housing Flange: 8.30 in
• Dimension At Service Clamp band: 10.2 in
• Distance To Clevis Pin Centerline From Face Of Service Housing: 4.75 in
• Length From Mounting Bracket To Spring Housing End: 9.90 in
• Piggyback Length: 7.40 in
• Push Rod Length From Face Of Service Housing: 14 in
• Push Rod Thread Size: 5/8-18 UNF in
• Inlet Position Angle: 90 deg
• Maximum Pressure: 150 psi
