Haldex Gold Seal Spring Brake 3030 | GC3030R

Description

The HDX GC3030R is a Gold Seal Spring Brake tailored for heavy-duty commercial vehicles. This specialized component delivers spring-applied and air-released braking capabilities, adhering to stringent testing and quality criteria to ensure dependable and secure braking actions. Widely employed in the commercial vehicle sector, it guarantees efficient and durable braking functionality, making a significant contribution to both the safety and overall performance of vehicles operating on roadways.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Finish: Powder Coated
• Housing Material: Steel
• Maximum Pressure: 150 psi
• Stud Length: 1.50 in
• Stroke Length: 2.50 in
• Stud Thread Size: 5/8-11 UNC in
• Inlet Port Thread Size: 3/8-18 NPTF in
• Stud Distance: 120.7 mm
• Dimension At Rolled Spring Housing Flange: 8.30 in
• Dimension At Service Clamp band: 10.2 in
• Distance To Clevis Pin Centerline From Face Of Service Housing:4.75 in
• Length From Mounting Bracket To Spring Housing End: 9 in
• Piggyback Length: 6.80 in
• Push Rod Length From Face Of Service Housing: 14 in
• Push Rod Thread Size: 5/8-18 UNF in
• Inlet Position Angle: 90 deg
• Air Port Thread Size: 3/8-18 NPTF in
• Quantity: 1
• Grade: 5
• Air Port Position: 90 deg
• Service Clamp band Position: 0 deg
