Haldex Brake Chamber Assembly T24, 2.50 | SC24L

Description

The HDX SC24L is a special unit used in vehicles to assist with braking. It has a stroke length of 2.50 inches, which determines how far the piston inside the unit can move. The SC24L chamber is a crucial part of the braking system as it transforms air pressure into mechanical force, allowing the brakes to be activated. It's important to regularly inspect and maintain the SC24L chamber assembly to ensure optimal brake performance and safe driving. Always adhere to the manufacturer's guidelines and safety protocols when working with brake components for proper installation and operation.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Air Port Position: 90 deg
• Service Clamp band Position: 0 deg
• Chamber Type: 24
• Stroke Length: 2.50 in
• Push Rod Length: 10 in
• Inlet Port Thread Size: 3/8-18 NPTF in
• Stud Distance: 120.7 mm
• Dimension At Service Clamp band: 9.4 in
• Distance To Clevis Pin Centerline From Face Of Service Housing: 4.75 in
• Length From Mounting Bracket To Spring Housing End: 3.80 in
• Push Rod Length From Face Of Service Housing: 10 in
• Inlet Position Angle: 90 deg
• Air Port Thread Size: 3/8-18 NPTF in
• Maximum Pressure: 150 psi
