Haldex 3" Stroke Length Service Chamber Brake | SC30LCW

Description

The HDX SC30LCW is a brake chamber assembly used in heavy-duty vehicle air brake systems. It has a 30-type chamber size with a 225 square-inch effective area. The assembly features a welded yoke that connects the push rod to the brake slack adjuster, allowing for proper brake actuation. It ensures safe and reliable stopping performance in commercial vehicles.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Air Port Position: 0 deg
• Width: 107 mm
• Stroke Length: 3 in
• Inlet Port Thread Size: 3/8-18 NPTF in
• Stud Distance: 120.7 mm
• Dimension At Service Clamp band: 8.3 in
• Distance To Clevis Pin Centerline From Face Of Service Housing: 4.75 in
• Length From Mounting Bracket To Spring Housing End: 4.20 in
• Push Rod Length From Face Of Service Housing: 1 in
• Inlet Position Angle: 0 deg
• Air Port Thread Size: 3/8-18 NPTF in
• Maximum Pressure: 150 psi
