In Stock!
Freightliner Wire Braided Air Compressor Discharge Line | A12-23236-100
SKU
FL A12-23236-100
MPN
A12-23236-100
Special Price
$52.04
Regular Price
$65.05
Have a Question for Our Team?
Our Customer Service team is ready to help.
Call 1.877.DL.ORDER or Email Us
Monday - Friday 8 AM - 4:30 PM ET
Description
The A12-23236-100 Line is specially crafted to facilitate the air discharge system of the compressor. It serves as a wire braided conduit that transports compressed air from the compressor to the relevant components within the air conditioning system. The wire braided design ensures sturdiness and resilience, enabling the line to withstand the demanding conditions of high-pressure air and temperatures within the air conditioning system.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Overall Length: 100 in
- Hose Inner Diameter: 0.50 in
- Hose Length: 97.56 in
- Hose Outer Diameter: 0.83 in
- Hose Wall Thickness: 0.17 in
- End 1 Thread Size: 7/8-14 in
- End 2 Thread Size: 7/8-14 in
- Standard Hose Size: #10
- Color: Black
- End 1 Fitting Type: Female Swivel Straight Fitting
- End 2 Fitting Type: Female Swivel Straight Fitting
- Nut Material: Steel
- Hose Material: EPDM (Synthetic Rubber)
- Nipple Material: Brass
- Working Temperature Range: -40 to +311 Deg. F
- Maximum Working Pressure: 250 psi
- Working Pressure: 250 psi
- Burst Pressure: 1000 psi
- Minimum Burst Pressure: 1000 psi
| Shipping Weight (lb) | 3.00 |
|---|---|
| Manufacturer | Freightliner |
| Shipping Length (in) | 12.00 |
| Shipping Width (in) | 12.00 |
| Shipping Height (in) | 2.00 |
| Returnable | Yes |
| Core Exchange | No |
