Freightliner Urea Line, Return, 2000mm | 04-32033-200

Description

The 04-32033-200 is a Freightliner Urea Line designed for return applications with a length of 2000mm. This component is integral to the operation of the urea system in vehicles equipped with selective catalytic reduction (SCR) technology. As a return line, it facilitates the circulation of unused urea fluid from the injection system back to the reservoir or tank for recirculation. With a length of 2000mm, this urea line is engineered to fit specific vehicle configurations while ensuring efficient urea recirculation under varying operating conditions. Manufactured to meet stringent performance standards, the 04-32033-200 Urea Line contributes to the overall effectiveness of the emission control system, aiding in the reduction of harmful emissions and compliance with environmental regulations.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Operating Temperature: -40 to +120 Deg.C
• Heating Capacity: 41.40 W
• Maximum Flow Rate: 3.17 gal/h
• Voltage: 14.20 V
• Ampere Rating: 12 A
• Color: Blue
• Material: EPDM (Synthetic Rubber)
• End 2 Fitting Type: 90 Degree
• Plug Type: RCT-2CAV, APEX2.8S, FC154200210
• Working Pressure: 130.50 psi
• Wall Thickness: 7.20 mm
• Center To Center Length: 2114 mm
• Tube Length: 2000 mm
• End 1 Fitting Angle: 90 deg
• End 2 Fitting Angle: 90 deg
• Line Outer Diameter: 18.40 mm
• Line Inner Diameter: 4 mm
• End 1 Fitting Thread Size: 3/8 in
• End 2 Fitting Thread Size: 5/16 in
