Freightliner Transmission Oil Cooler Return Hose, Coolant To Oil Cooling, ISB, DC | 07-23534-000

Description

The 07-23534-000 serves as a return hose within the transmission cooling system. Its primary function is to transport the coolant from the transmission oil cooler to the transmission once the fluid has been adequately cooled. It is vital to inspect and maintain this hose to ensure there are no damages or leaks that could potentially impact the efficiency of the transmission cooling system. It is crucial to use the hose specified for your vehicle model and type of transmission to guarantee a fit and dependable performance.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Temperature Rating: -40 to 300 Deg. F
• Maximum Operating Pressure: 250 psi
• Thickness: 3.30 mm
• Outer Diameter: 19.05 mm
• Inner Diameter: 12.45 mm
• Overall Length: 2301.02 mm
• Tube 2 Inner Diameter: 19.05 mm
• Tube 2 Wall Thickness: 7.62 mm
• End 1 Flare Fit Angle: 37 deg
• End 2 Flare Fit Angle: 90 deg
• Standard End 2 Fitting Size: #12
• Standard End 1 Fitting Size: #12
• Material: Steel
• Finish: Zinc Plated
• End 1 Fitting Type: Flare Nut and Sleeve
• End 2 Fitting Type: Quick Connector
