Freightliner Supply Tube, DD15, Left-Hand , 405 Radiator Position | 07-22153-001
SKU
FL 07-22153-001
MPN
07-22153-001
This item is unavailable online. Please contact your account manager or customer service at (800) 423 6967.
Have a Question for Our Team?
Our Customer Service team is ready to help.
Call 1.877.DL.ORDER or Email Us
Monday - Friday 8 AM - 4:00 PM ET
The Freightliner 07-22153-001 Supply Tube is designed for the left-hand side of the DD15 engine, specifically in the 405 radiator position. It can operate within a temperature range of -40 to 300 degrees Fahrenheit and has a maximum operating pressure of 250 psi. The tube has a 12.70 mm inner diameter for Tube 2 and it features a 37-degree flare fit angle and a 90-degree elbow fitting angle on both ends. The standard fitting size for both ends is #8 and the material is steel with a zinc-plated finish. The end fittings are of the female swivel nut type on both ends, ensuring secure and reliable connections for the DD15 engine's cooling system.
Description
The Freightliner 07-22153-001 Supply Tube is designed for the left-hand side of the DD15 engine, specifically in the 405 radiator position. It can operate within a temperature range of -40 to 300 degrees Fahrenheit and has a maximum operating pressure of 250 psi. The tube has a 12.70 mm inner diameter for Tube 2 and it features a 37-degree flare fit angle and a 90-degree elbow fitting angle on both ends. The standard fitting size for both ends is #8 and the material is steel with a zinc-plated finish. The end fittings are of the female swivel nut type on both ends, ensuring secure and reliable connections for the DD15 engine's cooling system.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Temperature Rating: -40 to 300 Deg. F
- Maximum Operating Pressure: 250 psi
- Thickness: 1.24 mm
- Outer Diameter: 12.70 mm
- Inner Diameter: 10.21 mm
- Overall Length: 2591.80 mm
- Tube 2 Inner Diameter: 12.70 mm
- End 1 Flare Fit Angle: 37 deg
- End 1 Elbow Fitting Angle: 90 deg
- End 2 Flare Fit Angle: 37 deg
- Standard End 2 Fitting Size: #8
- Standard End 1 Fitting Size: #8
- End 2 Elbow Fitting Angle: 90 deg
- Material: Steel
- Finish: Zinc Plated
- End 1 Fitting Type: Female Swivel Nut
- End 2 Fitting Type: Female Swivel Nut
| Shipping Weight (lb) | 91.00 |
|---|---|
| Manufacturer | Freightliner |
| Shipping Length (in) | 64.00 |
| Shipping Width (in) | 14.00 |
| Shipping Height (in) | 14.00 |
| Returnable | Yes |
| Core Exchange | No |
