Freightliner Main Heater Pipe Valve, S60 | 05-23135-001

Description

The 05-23135-001 part number corresponds to a heater pipe specifically designed for the main heating system in the S60 vehicle model. This pipe is equipped with a valve that helps control and regulate the flow of coolant through the heating system. Its role is vital as it ensures that heated coolant from the engine circulates to the heater core, providing warmth to the vehicle's interior during cold weather. The inclusion of this valve allows drivers to adjust the temperature and manage the flow of heated coolant, which improves heating efficiency and enables personalized climate control inside the cabin.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Material: Steel
• Finish: Painted
• End 1 Fitting Type: Flare With End Nut
• End 2 Fitting Type: Male Fitting
• Nut Material: Brass
• Maximum Pressure: 200 psi
• Outer Diameter: 0.75 in
• Inner Diameter: 0.65 in
• Wall Thickness: 0.05 in
• Center To Center Length: 7.52 in
• End 1 Flare Fit Angle: 45 deg
• End 1 Fitting Thread Size: 1 1/16-14 in
• End 2 Fitting Thread Size: 1/2-14 NPT in
