Freightliner ISX Turbocharger Oil Supply Tube | 07-22015-000
Have a Question for Our Team?
Description
The 07-22015-000 serves as an oil supply tube for the Freightliner ISX Turbocharger. It is designed to withstand temperatures ranging from -40 to 300 degrees Fahrenheit, ensuring its reliability in operating conditions. With an operating pressure of 250 psi, it efficiently delivers oil to the turbocharger, optimizing its performance. The tube has a diameter of 12.70 mm, a diameter of 10.21 mm and an overall length of 2586 mm, with a center-to-center length of 2054.50 mm. At both ends, it is equipped with elbow fittings at a 90-degree angle and uses #8 fitting sizes with female swivel nut types. Constructed from steel and finished with zinc plating, this tube offers both strength and corrosion resistance, making it a dependable component in turbocharger systems.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Temperature Rating: -40 to 300 Deg. F
- Maximum Operating Pressure: 250 psi
- Thickness: 1.24 mm
- Outer Diameter: 12.70 mm
- Inner Diameter: 10.21 mm
- Overall Length: 2586 mm
- Center To Center Length: 2054.50 mm
- Tube 2 Inner Diameter: 12.70 mm
- End 1 Elbow Fitting Angle: 90 deg
- Standard End 2 Fitting Size: #8
- Standard End 1 Fitting Size: #8
- End 2 Elbow Fitting Angle: 90 deg
- Material: Steel
- Finish: Zinc Plated
- End 1 Fitting Type: Female Swivel Nut
- End 2 Fitting Type: Female Swivel Nut
| Shipping Weight (lb) | 60.00 |
|---|---|
| Manufacturer | Freightliner |
| Shipping Length (in) | 81.00 |
| Shipping Width (in) | 16.90 |
| Shipping Height (in) | 6.00 |
| Returnable | Yes |
| Core Exchange | No |
