Freightliner Doser Urea Line, 2400MM | 04-28841-240

Description

The part number 04-28841-240 corresponds to a Urea line that is 2400 mm long and used in the doser system. The doser system plays a crucial role in modern diesel engines by aiding in selective catalytic reduction (SCR) and exhaust after treatment to reduce harmful emissions. The Urea line's main function is to deliver Diesel Exhaust Fluid (DEF) or Urea to the doser, which then injects it into the exhaust stream for breaking down harmful nitrogen oxides (NOx) into harmless nitrogen and water vapor. The length of 2400 mm indicates the specific size and application of this Urea line within the engine system.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Maximum Flow Rate: 3.17 gal/h
• Voltage: 12 V
• Color: Blue
• Material: Nylon
• End 1 Fitting Type: 90 Degree
• Plug Type: RCT-2CAV, APEX2.8S, FC154200210
• Working Pressure: 130.50 psi
• Wall Thickness: 1 mm
• Tube Length: 2400 mm
• End 1 Fitting Angle: 90 deg
• End 2 Fitting Angle: 90 deg
• Line Outer Diameter: 5 mm
• Line Inner Diameter: 3 mm
• End 1 Fitting Thread Size: 5/16 in
• End 2 Fitting Thread Size: 5/16 in
