Freightliner Diesel Exhaust Fluid Tank Return Line, Cummins | 04-28919-000

Description

The part number 04-28919-000 corresponds to a diesel exhaust fluid (DEF) line designed for tank return in Cummins engines. This line is responsible for returning the DEF from the tank to the engine after it has been used in the exhaust after-treatment process. Proper functioning of this line is crucial for ensuring the correct flow and recirculation of DEF, which helps reduce harmful emissions and maintain compliance with emission regulations.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Maximum Flow Rate: 3.17 gal/h
• Voltage: 12 V
• Color: Blue
• Material: Nylon
• End 1 Fitting Type: 90 Degree
• End 2 Fitting Type: Straight
• Plug Type: RCT-2CAV, APEX2.8S, FCI54200211
• Working Pressure: 130.50 psi
• Wall Thickness: 1 mm
• Tube Length: 530 mm
• End 1 Fitting Angle: 90 deg
• End 2 Fitting Angle: 180 deg
• Line Outer Diameter: 5 mm
• Line Inner Diameter: 3 mm
• End 1 Fitting Thread Size: 5/16 in
• End 2 Fitting Thread Size: 3/8 in
