Freightliner Charge Air Cooler Hose Clamp | 04-30123-000

Description

The part with the code 04-30123-000 is specifically made for attaching exhaust components together in vehicles equipped with ISB engines. Its purpose is to securely connect and fasten the different parts of the exhaust system. By properly securing these components, we can prevent leaks and ensure that the engine performs efficiently. This clamp plays a crucial role in keeping the exhaust system stable and correctly aligned.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Tightening Torque: 5.60 Nm
• Bolt Material: stainless steel
• Band Material: stainless steel
• Screw Material: stainless steel
• Insert Material: stainless steel
• Insert Quantity: 3
• Thickness: 0.04 in
• Maximum Diameter: 3.17 in
• Minimum Diameter: 2.62 in
• Bolt Thread Size: 1/4-28 UNF-2A in
• Nominal Diameter: 76.20 mm
• Screw Length: 2.75 in
• Clamp Band Width: 0.75 in
• Band Width: 19.05 mm
• Band Thickness: 1.02 mm
• Insert Thickness: 1.27 mm
• Insert Apex Width: 6.07 mm
• Insert Depth: 4.83 mm
• Insert Angle: 40 deg
