Freightliner Air Compressor Metal In Rail Discharge Line | A12-26511-000

Description

The A12-26511-000 is a specific part designated for the air discharge system of a vehicle. This component is intended to be installed on the left-hand side of the vehicle and is related to air intake or exhaust functions. The part number uniquely identifies this component for replacement or maintenance purposes.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Overall Length: 25.33 in
• Tube Outer Diameter: 0.63 in
• Tube Wall Thickness: 0.05 in
• Center To Center Length: 24.39 in
• Tube Inner Diameter: 0.53 in
• End 1 Thread Size: 7/8-14 in
• End 1 Flare Fit Angle: 45 deg
• End 2 Thread Size: 7/8-14 in
• End 2 Flare Fit Angle: 45 deg
• Finish: Zinc Cobalt Coated
• End 1 Fitting Type: Male Connector
• End 2 Fitting Type: Male Connector
• Nut Material: Brass
• Tube Material: Steel
