Freightliner Air Compressor Discharge Line 50 in | A12-23236-050
SKU
FL A12-23236-050
MPN
A12-23236-050
$49.52
Have a Question for Our Team?
Our Customer Service team is ready to help.
Call 1.877.DL.ORDER or Email Us
Monday - Friday 8 AM - 4:30 PM ET
Description
The A12-23236-050 is an air discharge line for a compressor. It is wire braided, indicating that it is designed to withstand high-pressure applications and provide added durability and strength. The line's primary function is to carry compressed air from the compressor to other components in the air system such as air tanks or air brakes.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Overall Length: 50 in
- Hose Inner Diameter: 0.50 in
- Hose Length: 47.56 in
- Hose Outer Diameter: 0.83 in
- Hose Wall Thickness: 0.17 in
- End 1 Thread Size: 7/8-14 in
- End 2 Thread Size: 7/8-14 in
- Standard Hose Size: #10
- Color: Black
- End 1 Fitting Type: Female Swivel Straight Fitting
- End 2 Fitting Type: Female Swivel Straight Fitting
- Nut Material: Steel
- Hose Material: EPDM (Synthetic Rubber)
- Nipple Material: Brass
- Working Temperature Range: -40 to +311 Deg. F
- Maximum Working Pressure: 250 psi
- Working Pressure: 250 psi
- Burst Pressure: 1000 psi
- Minimum Burst Pressure: 1000 psi
| Manufacturer | Freightliner |
|---|---|
| Shipping Length (in) | 48.00 |
| Shipping Width (in) | 8.00 |
| Shipping Height (in) | 8.00 |
| Returnable | Yes |
| Weight (lb) | 1.01 |
| Core Exchange | No |
