In Stock!
Freightliner Air Compressor Discharge Line 30 in | A12-25822-030
SKU
FL A12-25822-030
MPN
A12-25822-030
Special Price
$61.86
Regular Price
$77.32
Have a Question for Our Team?
Our Customer Service team is ready to help.
Call 1.877.DL.ORDER or Email Us
Monday - Friday 8 AM - 4:30 PM ET
Description
The A12-25822-030 is an air discharge line, specifically a 90-degree bend type designated for the transfer of air from the air compressor to the air dryer. This particular hose has number 10 fittings and is 30 inches in length.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Overall Length: 30 in
- Hose Inner Diameter: 0.50 in
- Hose Length: 27.50 in
- Hose Outer Diameter: 0.83 in
- Hose Wall Thickness: 0.17 in
- End 1 Thread Size: 7/8-14 in
- End 1 Flare Fit Angle: 45 deg
- End 1 Elbow Fitting Angle: 90 deg
- End 2 Thread Size: 7/8-14 in
- Standard Hose Size: #10
- Color: Black
- End 1 Fitting Type: Female Swivel Elbow Fitting
- End 2 Fitting Type: Female Swivel Straight Fitting
- Nut Material: Steel
- Hose Material: EPDM (Synthetic Rubber)
- Nipple Material: Steel
- Working Temperature Range: -40 to +311 Deg. F
- Maximum Working Pressure: 250 psi
- Working Pressure: 250 psi
- Minimum Burst Pressure: 1000 psi
| Shipping Weight (lb) | 5.00 |
|---|---|
| Manufacturer | Freightliner |
| Shipping Length (in) | 36.00 |
| Shipping Width (in) | 4.00 |
| Shipping Height (in) | 4.00 |
| Returnable | Yes |
| Core Exchange | No |
