Freightliner Air Compressor Discharge Line 30 in | A12-22571-030

Description

The A12-22571-030 refers to a Teflon air discharge line that measures 30 inches in length. It is specifically designed to handle the release of compressed air within pneumatic systems. Teflon is chosen for such applications due to its exceptional ability to withstand high temperatures, chemicals and friction, making it an ideal choice for transporting air under diverse conditions. The 30 inch measurement indicates the precise size of the line, which is crucial for seamless fitting and integration into the pneumatic system.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Overall Length: 30 in
• Hose Inner Diameter: 0.50 in
• Hose Length: 27.38 in
• End 1 Thread Size: 7/8-14 in
• End 1 Flare Fit Angle: 37 deg
• End 1 Elbow Fitting Angle: 90 deg
• End 2 Thread Size: 7/8-14 in
• End 2 Flare Fit Angle: 37 deg
• Standard Hose Size: #8
• Color: Silver
• End 1 Fitting Type: Female Swivel Elbow Fitting
• End 2 Fitting Type: Female Swivel Straight
• Nut Material: Steel
• Hose Material: Polytetrafluoroethylene
• Nipple Material: Steel
• Operating Temperature: -100 to450 Deg. F
• Maximum Working Pressure: 1350 psi
• Working Pressure: 1350 psi
