Freightliner Air Brake 80 in. Air Line | 12-21021-080

Description

The 12-21021-080 is a hose assembly with a #8 size designed for high-pressure applications. It comes with two SAE 45 swivel end fittings, which provide flexibility and ease of installation. This hose is commonly used for conveying hydraulic fluid or other media between components in hydraulic systems. The SAE 45 swivel end fittings allow for rotation, making it easier to connect the hose to other components without twisting the hose itself.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Temperature Rating: -50 to212 Deg. F
• Color: Black
• Material: Synthetic Rubber
• End 1 Fitting Type: End Nut Fitting
• End 2 Fitting Type: End Nut Fitting
• Maximum Working Pressure: 225 psi
• Working Pressure: 225 psi
• Minimum Burst Pressure: 900 psi
• Length: 80 in
• Thickness: 0.19 in
• Tube Outer Diameter: 0.88 in
• Thread Size: 3/4-16 in
• Tube Inner Diameter: 0.50 in
