Freightliner Air Brake 23 in. Air Line | 12-21022-023

Description

The 12-21022-023 is a #8 size hose assembly with a 06MPT (Male Pipe Thread) fitting on one end and a SAE 45 swivel fitting on the other end. This hose is designed for use in high-pressure applications, providing efficient fluid transfer and fluid power capabilities. It is commonly utilized in hydraulic systems, air conditioning systems and various industrial applications. The combination of fittings allows for easy and secure connections during installation, ensuring reliable performance.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Color: Black
• End 1 Fitting Type: Swivel Nut
• End 2 Fitting Type: Male
• Hose Material: Synthetic Rubber with Fiber Reinforcement
• Maximum Working Pressure: 225 psi
• Minimum Burst Pressure: 900 psi
• Operating Temperature: -46 to 100 Deg.C
• Center To Center Length: 584.20 mm
• End 1 Thread Size: 3/4-16 in
• End 1 Flare Fit Angle: 45 deg
• End 2 Thread Size: 3/8-18 in
• Standard Hose Size: #8
