Freightliner A/C Hose Assembly | A22-66834-008

Description

The A22-66834-008 is a refrigerant hose or tube designed for applications involving C15 C16 SAN and 12 systems. It features the following specifications: an inner diameter of 0.41 inches, a length of 19.69 inches, an outer diameter of 0.73 inches and a center-to-center length of 32.16 inches. The hose wall thickness is 0.16 inches. It has end fittings with angles of 132 degrees and 90 degrees at each end respectively. The standard hose size and fitting size are both #8, and the hose has a burst pressure of 1000 psi.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Hose Inner Diameter: 0.41 in
• Hose Length: 19.69 in
• Hose Outer Diameter: 0.73 in
• Center To Center Length: 32.16 in
• Hose Wall Thickness: 0.16 in
• End 1 Fitting Angle: 132 deg
• End 2 Fitting Angle: 90 deg
• Standard End 1 Fitting Size: #8
• Standard Hose Size: #8
• Burst Pressure: 1000 psi
