Freightliner A/C Hose Assembly | A22-60361-001

Description

The A22-60361-001 is a hose assembly specifically created for air conditioning (A/C) systems. Its purpose is to connect the condenser to the receiver dryer (RD) using a hose of #6 size. This assembly has a yellow color with a zinc-plated finish and it features Stat-O-Seal type rubber fittings with steel retainers at both ends. The hose itself is made from steel tubing material and has dimensions such as an inner diameter of 0.88 inches and a length of 10.04 inches. It is built to withstand a burst pressure of 1250 psi.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Color: Yellow
• Finish: Zinc Plated
• End 1 Fitting Type: Stat-O-Seal
• End 2 Fitting Type: Stat-O-Seal
• End 1 Fitting Material: Rubber with Steel Retainer
• End 2 Fitting Material: Rubber with Steel Retainer
• Tube 1 Material: Steel
• Tube 2 Material: Steel
• Hose Inner Diameter: 0.88 in
• Hose Length: 10.04 in
• Tube 1 Wall Thickness: 0.05 in
• Tube 2 Inner Diameter: 0.28 in
• Tube 1 Outer Diameter: 0.38 in
• Tube 2 Wall Thickness: 0.05 in
• Tube 2 Outer Diameter: 0.38 in
• Tube 1 Inner Diameter: 0.28 in
• Standard End 2 Fitting Size: #6
• Standard End 1 Fitting Size: #6
• Standard Hose Size: #16
• Burst Pressure: 1250 psi
