Freightliner A/C Hose Assembly | A22-57505-000

Description

The A22-57505-000 is an A/C hose assembly designed for #6 fittings specifically connecting to a receiver-junction block (REC-JBLOCK) in a vehicle's air conditioning system. The hose is constructed with durable materials: nylon for the hose itself, aluminum for the tubes and elastomer and natural rubber for the cover. It features fittings of rubber with steel retainers at both ends, ensuring secure connections. The hose's dimensions include an inner diameter of 0.32 inches, a length of 11.93 inches and an outer diameter of 0.62 inches. The tube outer diameter is 0.38 inches and the tube wall thickness is 0.05 inches. The hose offers a strong performance with a burst pressure rating of 1250 psi, making it suitable for the demands of an A/C system.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Fitting Type: Stat-O-Seal
• Hose Material: Nylon
• Tube Material: Aluminum
• Cover Material: Elastomer and Natural Rubber
• End 1 Fitting Material: Rubber with Steel Retainer
• End 2 Fitting Material: Rubber with Steel Retainer
• Hose Inner Diameter: 0.32 in
• Hose Length: 11.93 in
• Hose Outer Diameter: 0.62 in
• Tube Outer Diameter: 0.38 in
• Tube Wall Thickness: 0.05 in
• Hose Wall Thickness: 0.15 in
• Tube Inner Diameter: 0.28 in
• Standard Fitting Size: #6
• Standard Hose Size: #6
• Burst Pressure: 1250 psi
