Freightliner A/C Hose Assembly | A22-53680-323

Description

The A22-53680-323 represents an A/C hose assembly made of nylon hose material and covered with elastomer. It is equipped with a Stat-O-Seal fitting on one end and an adapter with a 90-degree angle on the other. The hose itself has a diameter of 0.41 inches, measures 36.38 inches in length and has an outer diameter of 0.73 inches. Additionally, this assembly includes aluminum and steel tubes that can withstand a burst pressure of up to 1000 psi.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• End 1 Fitting Type: Stat-O-Seal
• End 2 Fitting Type: Adapter
• Hose Material: Nylon
• Cover Material: Elastomer
• End 1 Fitting Material: Rubber with Steel Retainer
• Tube 1 Material: Aluminum
• Tube 2 Material: Steel
• Hose Inner Diameter: 0.41 in
• Hose Length: 36.38 in
• Hose Outer Diameter: 0.73 in
• Tube Outer Diameter: 0.50 in
• Tube Wall Thickness: 0.05 in
• Center To Center Length: 47.72 in
• Hose Wall Thickness: 0.16 in
• Tube Inner Diameter: 0.40 in
• End 2 Fitting Angle: 90 deg
• Standard Fitting Size: #8
• Standard Hose Size: #8
• Burst Pressure: 1000 psi
