Freightliner A/C Hose Assembly | A22-53330-001

Description

The A22-53330-001 is an A/C hose assembly designed with specifications for specific use. It features a #8 hose size and has a length of 20.87 inches. The hose is constructed with nylon material and includes steel fittings for durability. The end 1 fitting is a beaded female swivel nut with a 42-degree angle and a 3/4-16 inch thread size. The end 2 fitting is an adapter with a female swivel nut and a 90-degree angle featuring a 1-14 UNS 2B inch thread size. The hose assembly is designed to withstand a burst pressure of up to 1000 psi, making it suitable for A/C applications.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• End 1 Fitting Type: Beaded Female Swivel Nut
• End 2 Fitting Type: Adapter with Female Swivel Nut
• Hose Material: Nylon
• Fitting Material: Steel
• Tube Material: Steel
• Cover Material: Elastomer
• Hose Inner Diameter: 0.41 in
• Hose Length: 20.87 in
• Hose Outer Diameter: 0.73 in
• Tube Outer Diameter: 0.50 in
• Tube Wall Thickness: 0.05 in
• Hose Wall Thickness: 0.16 in
• Tube Inner Diameter: 0.40 in
• End 1 Fitting Angle: 42 deg
• End 2 Fitting Angle: 90 deg
• End 1 Fitting Thread Size: 3/4-16 in
• End 2 Fitting Thread Size: 1-14 UNS 2B in
• Standard End 1 Fitting Size: #8
• Standard Hose Size: #8
• Burst Pressure: 1000 psi
