Freightliner A/C Hose Assembly | A22-52177-300

Description

The A22-52177-300 is an A/C hose assembly designed for vehicles like S60 SAN and 120. It features a nylon hose material, steel fittings and a steel tube with elastomer cover. The hose has dimensions of 0.63-inch inner diameter, 33.50-inch length and 0.97-inch outer diameter. It is built to withstand pressures up to 1000 psi, making it suitable for A/C systems that require efficient cooling and climate control.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• End 2 Fitting Type: Adapter
• Hose Material: Nylon
• Fitting Material: Steel
• Tube Material: Steel
• Cover Material: Elastomer
• Hose Inner Diameter: 0.63 in
• Hose Length: 33.50 in
• Hose Outer Diameter: 0.97 in
• Tube Outer Diameter: 0.63 in
• Tube Wall Thickness: 0.05 in
• Center To Center Length: 42.72 in
• Hose Wall Thickness: 0.17 in
• Tube Inner Diameter: 0.53 in
• End 1 Fitting Angle: 30 deg
• End 2 Fitting Angle: 90 deg
• Switch Port Thread Size: M12 mm
• Standard End 2 Fitting Size: #10
• Standard End 1 Fitting Size: #10/12
• Standard Hose Size: #12
• Burst Pressure: 1000 psi
