Freightliner A/C Hose Assembly | A22-41332-022

Description

The A22-41332-022 is an air conditioning hose assembly that measures 58 inches in length. It is equipped with fittings of size #10/12 and has a 90-degree angle on both ends (one end features a female swivel nut adapter, while the other end is beaded with a female swivel nut). The hose assembly is made using synthetic rubber for the hose material and steel fittings, while the tube material consists of a combination of elastomer and natural rubber for the cover material.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• End 1 Fitting Type: Adapter with Female Swivel Nut
• End 2 Fitting Type: Beaded with Female Swivel Nut
• Hose Material: Synthetic Rubber
• Fitting Material: Steel
• Tube Material: Steel
• Cover Material: Elastomer and Natural Rubber
• Hose Inner Diameter: 0.63 in
• Hose Length: 53.38 in
• Hose Outer Diameter: 0.97 in
• Tube Outer Diameter: 0.63 in
• Tube Wall Thickness: 0.05 in
• Center To Center Length: 58 in
• Hose Wall Thickness: 0.17 in
• Tube Inner Diameter: 0.53 in
• Fitting Angle: 90 deg
• End 1 Fitting Thread Size: 1-14 UNS 2B in
• End 2 Fitting Thread Size: 7/8-14 in
• Standard End 2 Fitting Size: #10/12
• Standard Hose Size: #12
• Burst Pressure: 1000 psi
