Freightliner A/C Hose Assembly | A22-41331-053

Description

The A/C hose assembly with the part number A22-41331-053 has a length of 79 inches. It has fittings with a 90 degree angle on one end, specifically an adapter with a female swivel nut and a straight fitting with a crimp beaded female swivel nut on the other end. The hose itself is made of synthetic rubber, while the fittings and tube material are steel. It also features an elastomer cover material. The inner diameter of the hose is 0.41 inches and its outer diameter is 0.73 inches, with a hose wall thickness of 0.16 inches. On the other hand, the tube has an outer diameter of 0.50 inches and a wall thickness of 0.05 inches, with an inner diameter measuring at 0.40 inches.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• End 1 Fitting Type: Adapter with Female Swivel Nut
• End 2 Fitting Type: Crimp, Beaded Female Swivel Nut
• Hose Material: Synthetic Rubber
• Fitting Material: Steel
• Tube Material: Steel
• Cover Material: Elastomer
• Hose Inner Diameter: 0.41 in
• Hose Length: 76 in
• Hose Outer Diameter: 0.73 in
• Tube Outer Diameter: 0.50 in
• Tube Wall Thickness: 0.05 in
• Center To Center Length: 79 in
• Hose Wall Thickness: 0.16 in
• Tube Inner Diameter: 0.40 in
• End 1 Fitting Angle: 90 deg
• End 1 Fitting Thread Size: 1-14 UNS 2B in
• End 2 Fitting Thread Size: 3/4-16 UNF 2B in
• Standard End 2 Fitting Size: #8
• Standard Hose Size: #8
• Burst Pressure: 1000 psi
